Material: FR4 Board thickness: 1.6mm Number of layers: 2 layers Process: Immersion Gold Min drilling hole: 0.3mm Minimum line width: 0.127mm Minimum line space: 0.127mm
+86 0755-81772911
| Memory PCB | |||
| Substrate: | FR4 | Layers: | 2 layers |
| Dielectric constant: | 4.3 | Board thickness: | 1.6mm |
| Thickness of outer copper foil: | 1oz | hickness of inner copper foil: | / |
| Surface treatment method: | Immersion gold | Minimum hole diameter: | 0.25mm |
| Minimum line width: | 0.1mm | Minimum line space: | 0.1mm |
| Application areas: | device memory | Features: | 25um copper hole, gold fingers need beveled edges, and black oil bridges need to be retained |
![230463ee94ac4c1f8ad3fad5c722e0f0_74[1].jpg](/upload/default/20210203/f7f994ae5bf349373994585610e095fb.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_74[1].jpg")
![230463ee94ac4c1f8ad3fad5c722e0f0_72[1].jpg](/upload/default/20210203/521adb2fd5197fee84a451ba1b30fe57.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_72[1].jpg")
![230463ee94ac4c1f8ad3fad5c722e0f0_70[1].jpg](/upload/default/20210203/b7f3e139f74004a7eb1a19c526a8168c.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_70[1].jpg")
![230463ee94ac4c1f8ad3fad5c722e0f0_68[1].jpg](/upload/default/20210203/523de4fcdd3a12f0110ab91726c890b4.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_68[1].jpg")
![230463ee94ac4c1f8ad3fad5c722e0f0_66[1].jpg](/upload/default/20210203/fee57de60a73139556cf8d57b5a1c326.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_66[1].jpg")
![230463ee94ac4c1f8ad3fad5c722e0f0_64[1].jpg](/upload/default/20210203/647188f9a04b9035f0ab5edf88a7020c.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_64[1].jpg")
![230463ee94ac4c1f8ad3fad5c722e0f0_62[1].jpg](/upload/default/20210203/7571de98ba2bdfc076818fa01f109553.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_62[1].jpg")
![230463ee94ac4c1f8ad3fad5c722e0f0_60[1].jpg](/upload/default/20210203/6aff54961c3dbafa70c4189ed24b3164.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_60[1].jpg")
![230463ee94ac4c1f8ad3fad5c722e0f0_58[1].jpg](/upload/default/20210203/fc43e0ccefe419fdcba433a91bfa3f25.jpg "230463ee94ac4c1f8ad3fad5c722e0f0_58[1].jpg")
Widely used in: communications, consumer electronics, industrial control, security, automobiles, power supplies, smart home, medical, military and other industries.
