360 circuit board

Material: FR4 Number of layers: 2 layers Process: Immersion Gold Minimum drilling: 0.3mm Minimum line width: 0.3mm Minimum line space: 0.3mm Features: matt black ink, strict appearance requirements 【MORE】

Special circuit board

Material: FR4 Number of layers: 2 layers Process: Immersion Gold 3U" Minimum drilling: 0.3mm Minimum line width: 0.3mm Minimum line space: 0.3mm Features: 3.2mm thick plate, need bevel edge, countersunk hole process 【MORE】

Carbon oil pcb

Material: FR4 Number of layers: 2 layers Process: spray tin + carbon oil Minimum drilling: 0.3mm Minimum line width: 0.2mm Minimum line spacing: 0.2mm Features: printed carbon oil 【MORE】

Blue plastic circuit board

Material: FR4 Number of layers: 2 layers Process: Lead-free tin spray + blue glue Minimum drilling: 0.3mm Minimum line width: 0.3mm Minimum line space: 0.3mm Features: Need to print Peters blue glue 【MORE】

Communication circuit board

Material: Teflon Number of layers: 2 layers Process: Shen tin Minimum drilling: 0.3mm Minimum line width: 0.5mm Minimum line space: 0.5mm Features: high frequency sheet, low dielectric constant 【MORE】

Vernier caliper circuit board

Material: FR4 Number of layers: 2 layers Process: Electric gold Min drilling hole: 0.2mm Minimum line width: 0.1mm Minimum line space: 0.1mm Feature: Bonding board, line spacing 0.1mm can not be deviated, and repairs are not accepted 【MORE】

WIFI circuit board

Material: FR4 Number of layers: 2 layers Process: Immersion Gold Minimum Drilling: 0.2mm Minimum line width: 0.127mm Minimum line space: 0.127mm Features: half hole impedance board, white silk screen requires flatness 【MORE】

Halogen-free keyboard PCB

Material: FR4- halogen free Number of layers: 2 layers Process: OSP Minimum drilling hole: 0.3mm Minimum line width: 0.2mm Minimum line space: 0.2mm Features: The whole process is halogen-free, and the thickness of the board is thinner than 0.3mm 【MORE】

Mouse circuit board

Material: FR4 Number of layers: 2 layers Process: OSP Minimum drilling: 0.3mm Minimum line width: 0.2mm Minimum line spacing: 0.2mm Features: Irregular shape 【MORE】
